Puck Lights for Undercabinet and Cove Locations

American Lighting 3.2 Watt Omni Single LED Puck Light, 12V, Add to Omni Puck Light Kit

SKU: OMNI-1-BK | Ordering Code: OMNI-1-BK  | UPC: 714176001623

$20.70each
Add to Cart
Save to BulbTrack ?

Quickly and easily order the products you have purchased in the past or plan to order in the future by simply adding them to your My BulbTrack page.

Once a product has been added to My BulbTrack, ordering it is as easy as entering the quantity or clicking on the product image. You can even add notes to each product to record where it is used in your business or home.

Ships from SupplierUsually ships in 1-2 business days.

Add 5 to your cart to get free ground shipping *

Product Highlights

  • Energy efficient replacement for a conventional 20 watt bulb
  • Estimated life of 27.4 years based on 3 hours use per day
Description

Lighting Facts Per Bulb

Brightness 140 lumens
Estimated Yearly Energy Cost $0.39
Based on 3 hrs/day, 11¢/kWh
Cost depends on rates and use
Life
Based on 3 hrs/day27.4 years
Light Appearance
WarmCool
2700 K
Energy Used3.2 watts

American Lighting Omni LED puck lights are durable low voltage and available in 2700K warm white.

This single LED puck light is used to add to a 3-pack Omni LED puck light kit. Will not work by itself. Driver needed to operate.

  • Includes 78" lead wire and mounting hardware
  • Zinc alloy LED housing with aluminum heat sink
  • Stamped steel surface collar with black finish
  • Polycarbonate lens diffuses light
  • Over twice as bright as xenon puck lights
  • Dimmable with 15-100% light control (puck quantity and dimmer type depend upon driver used)
  • Spring steel clips secure housing into surface collar with a snap-fit, and retain recessed pucks securely in place
  • Surface mount or recess mount (2-1/4” cut-out)
  • Maximum run depends on capacity of driver

Product Documents

Full Specs

Brand

American Lighting

Product Line

Omni
Energy Used
A rating, expressed in watts, to indicate the rate at which a lamp consumes energy. Also known as wattage value.
3.2 Watts
Incandescent/Halogen Equivalent
The wattage value of an incandescent or halogen lamp of similar brightness.
20 Watts

Line Voltage

12
CRI
Color Rendering Index is an international system used to rate a lamp's ability to render object colors. The higher the CRI (based upon a 0-100 scale) the richer and more accurately colors generally appear. CRI differences among lamps are not usually visible to the eye unless the difference is more than 3-5 points.
80
Color Temperature (Kelvin)
An expression of the hue of the light emitted, measured in degrees Kelvin. Usually expressed by a four digit number followed by (k), such as 2700k. Higher temperatures indicate whiter, "cooler" colors, while lower temperatures indicate yellower, "warmer" colors. Some common Kelvin temperature benchmarks are 2700k (warm white), 3500k (neutral white), 4100k (cool white), 5000k (bright white), and 6500k (daylight).
2700
Brightness (Lumens)
A rating of the initial light output of a bulb, rated after 100 hrs of operation. Lumens are a measure of how much light falls on one square foot of area, one foot away from the light source.
140
Average Rated Life (hr)
A measurement of the average length of time, between first use and the point when 50% of the lamps tested have stopped functioning, , using an operating cycle of 3 hours on, 20 minutes off.
30000
Beam Angle (°)
The width of a light beam, expressed in degrees. The beam angle is often part of the ordering code for reflector lamps. For example, a 50PAR30/HIR/NFL25 is a 50-watt PAR30 narrow flood lamp with a beam angle of 25 degrees.
120
Bulb Type Supplied
Type of bulb supplied with the fixture
LED
Height (in)
For ballasts and fixtures, height is the measurement of total vertical distance from the top of the product to the bottom expressed in inches.
0.7
Diameter (in)
Light bulbs: a measurement of a bulb's width taken at the widest point of the bulb. Fixtures: the measurement across the widest point of a circular fixture.
2.5
Finish
The decorative finish of the item.
Black

Housing

Zinc alloy

Mounting

Surface or recessed

Warranty

3 year limited

Linkable

Yes
Dimmable
Indicates whether a product can be dimmed in conjunction with a suitable dimmer control.
Yes
